Troubleshoot

Each test generates one of the following result codes:

CODE Description

PASS The test was successful.

FAIL The test was unsuccessful.

SKIPPED The test was skipped because a test on which it depended failed,

or it was not supported by the service provider equipment to

which it is connected.

PENDING The test timed out without producing a result. Try running the

test again.

WARNING The test was unsuccessful. The Service Provider equipment your

Gateway connects to may not support this test.
